Flygt DX35-5/B 107673060 Waste Water Pump 415v #2907

Flygt DX35-5/B 107673060 – 0.55kW 415V Submersible Waste Water Pump #2907

The Flygt DX series are compact submersible electric pumps designed for pumping effluent and drainage water containing suspended solids. The DX35-5/B is suitable for residential, commercial and light industrial duties such as sump emptying, septic tank transfer and dewatering of flooded areas.

This unit is supplied as new, unused surplus stock and has not been installed. Minor cosmetic marks may be present from storage.

• Model: Flygt DX35-5/B
• Part number: 107673060
• Motor rating: 0.55 kW – three-phase
• Voltage: 380-415V, 50Hz, 2-pole
• Discharge connection: Rp 1½" threaded (female)
• Solids passage: up to 35 mm
• Impeller: twin-channel DX type
• Maximum immersion depth: 5 m
• Insulation class: F (155 °C)
• Protection rating: IPX8
• Power cable: H07RN-F (three-phase version supplied without plug)
• Supplied with 2 year guarantee

Need help confirming suitability?
Call us on 01803 220416 for technical advice.

Applications

• Pumping of effluent
• Emptying of septic tanks and residential sumps
• Draining of flooded basements and garages
• General drainage of clean and dirty water

Technical Features

• DRIVELUB seal system with oil chamber and silicon carbide mechanical seal
• Dry motor construction
• Thermal overload protection via internal motor protection
• Multi-seal barrier providing high resistance to infiltration

Operating limits:
• Maximum liquid temperature: 35 °C (fully submerged)
• Maximum immersion depth: 5 m

Delivery & Shipping

• Next working day dispatch available (order before 4pm)
• Same-day courier available – please call for a quote
• UK and international delivery available
• International shipping costs confirmed after checkout

Manufacturer specification:
Full technical details can be found in the official Flygt catalogue:
View Flygt DX series technical catalogue (50Hz)

Technical note – voltage:
Voltage is shown as 415V in the listing for simplified search purposes. This pump is the three-phase 380-415V, 50Hz version. Electrical connection must always follow the motor nameplate and be carried out by a qualified electrician.

Frequently Asked Questions

What does DX35-5/B mean?

• DX – Flygt compact drainage and wastewater pump range
• 35-5 – size within DX family with 35 mm solids passage
• B – series variant designation
• 0.55 kW – motor power (three-phase)
• Rp 1½" – threaded discharge connection

What type of impeller does this pump use?

The DX35 model uses a twin-channel impeller designed to handle liquids with suspended solids up to 35 mm in diameter while maintaining good hydraulic performance.

Can it handle solids?

Yes — the DX35 is designed for liquids containing suspended solids up to 35 mm, making it suitable for typical wastewater and drainage duties.

Is this the vortex version?

No — this is the standard DX model with twin-channel impeller. The vortex alternative would be the DXV version.

Does it include a float switch?

Three-phase DX pumps are normally supplied without float switch. Control should be provided via an external panel or level control appropriate to the installation.

Do you offer technical support?

Yes — we provide free technical advice prior to purchase. Please call 01803 220416.

About Our Stock

We specialise in supplying new and unused surplus pumps, allowing us to offer premium equipment at highly competitive prices. All pumps are inspected prior to dispatch and supplied with guarantee.
